Integra DRX-8.4 User Manual

14
Front Panel (European, Australian and Asian models)
S T U V
P
Q R
KL M N O
K Info button: Switches the information on the
display. ( →p82)
L Setup button: You can display advanced setting
items on the TV and the display to have a more
enjoyable experience with this unit. ( →p126)
M Cursor buttons ( / / / ) and Enter
button: Select an item with the cursors, and
press Enter to conrm your selection. When
using TUNER, use them to tune in to stations.
( →p88)
N Return button: Returns the display to the
previous state while setting.
O Master Volume
P Zone 2 button: Controls the multi-zone function.
( →p108)
O󰀨 button: Switches the multi-zone function o󰀨.
Q Zone 3 button: Controls the multi-zone function.
( →p110)
O󰀨 button: Switches the multi-zone function o󰀨.
R Whole House Mode button: Enable the
WHOLE HOUSE MODE function to play the
same source in all rooms that are multi-zone-
connected. ( →p112)
O󰀨 button: Switches the WHOLE HOUSE
MODE function o󰀨.
S Phones jack: Connect headphones with a
standard plug (ø1/4″/6.3 mm).
T Setup Mic jack: Connect the supplied speaker
setup microphone. ( →p170, p172)
U Input selector buttons: Switches the input to
be played.
V AUX Input HDMI jack: Connect a video camera,
etc. using an HDMI cable. ( →p70)

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
