Appendix
Audio Inputs North American and Taiwanese models European, Australian and Asian models
Analog 6 (RCA×4, PHONO×1, XLR×1)
Digital
5 (COAXIAL×2, OPTICAL×3)
• Supported sampling rates for PCM signals (stereo, mono) from a digital input are 32 kHz, 44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz/16 bit, 20 bit, and 24 bit.
Audio Outputs North American and Taiwanese models European, Australian and Asian models
Analog
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R,
HEIGHT 1 L/R, HEIGHT 2 L/R, SUBWOOFER
ZONE 2 PRE/LINE OUT or ZONE B LINE OUT,
ZONE 3 PRE/LINE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R, HEIGHT 1 L/R or FRONT Bi-AMP, HEIGHT 2
L/R or CENTER Bi-AMP (North American and Taiwanese models support banana plugs)
Phones 1 (ø 6.3 mm, 1/4")
Others North American and Taiwanese models European, Australian and Asian models
Setup Mic 1 (Front)
RS-232 1
12V TRIGGER OUT 3 (A:100 mA, B:25 mA, C:25 mA)
IR IN × 2(A/B), OUT × 1
Specications and features are subject to change without notice.
