Speaker Layout
5.1.4 Channel System
5.1.4 ch (Top Middle and Rear High)
( →p37)
5.1.4 ch (Top Front and Dolby Enabled
Speakers (Surround)) ( →p37)
5.1.4 ch (Dolby Enabled Speakers (Front and
Surround)) ( →p37)
5.1.4 ch (Dolby Enabled Speakers (Front)
and Rear High) ( →p37)
5.1.4 ch (Dolby Enabled Speakers (Front) and
Top Rear) ( →p37)
5.1.4 ch + ZONE 2/ZONE 3 ( →p37)
Zone 3Zone 3
Main Room
Zone 2Zone 2
