Integra DRX-8.4 - Page 48

7.1.2ch
7.1ch
5.1.2ch
5.1.4ch
7.1.4ch
5.1ch
48
Speaker Connections
 7.1 Channel System (Bi-Amping the Speakers) + ZONE SPEAKER (ZONE 2)
SL SR
SBL SBR
C
SW
FL FR
MAIN ROOM
– Playing Back (ZONE 2) ( →p108)
ZONE 2
FL(Z2)FR(Z2)
Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of
your speakers as well.
• Surround back speakers need to be connected to the HEIGHT 2 jacks.
