Integra DRX-8.4 User Manual

5
Playing Back 105
Multi-zone 107
Playing Back (ZONE 2) 108
Playing Back (ZONE 3) 110
WHOLE HOUSE MODE 112
Playing di󰀨erent audio and video 113
Displaying Your Favorite Video on TV While Playing
Music 113
Cinema Dedicated Mode 115
Using "Cinema Dedicated" 115
Using "Cinema Dedicated Net O󰀨" 115
Playing music les saved on a USB storage device 116
USB Storage Device Requirements 117
Music Server 118
Music Server notes 118
Windows Media
®
Player 12 settings 118
Playing Back 119
Play Queue 121
Adding Play Queue Information 121
Sort and Delete 121
Playing Back 122
Connecting a transmitter for playback 123
Connections 123
Setting Up 123
Playing Back 123
Setup
Setup Menu 126
Menu list 126
1. Input/Output Assign 129
2. Speaker 134
3. Audio Adjust 143
4. Source 146
5. Listening Mode Preset 148
6. Hardware 149
7. Multi Zone 162
8. Miscellaneous 164
Web Setup 166
Menu operations 166
Initial Setup with Auto Start-up Wizard 167
Operations 167
1. Speaker Setup 168
2. Multi Zone Sound Check 169
3. ARC Setup 169
4. Room EQ 169
Integra Control Pro 173
Main features 173
Initial Setup 173
Dirac Live 174

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
