NOTE A link cable can be used to connect the system rack to an adjacent expansion rack, as shown in the
following diagram. A loopback connector in each rack must be removed to install the link cable.
Link Cable
No connection to
optional devices.
Front of S
y
stem Rac
k
Front of Expansion Rack
5
