82
J9, MCBL101A, Intruder alert
Pin
Signal
1 Intruder Alert (chassis open)
2 Ground
J13/14/15, MCBL093A, Fan power
Pin
Signal
1 +12V
2 Fan Tach
3 Ground
Service Notice
Early releases of the system included a cable (MCBL107A) that connected J12 on the power
distribution board to J3 on the RAID sensor board of the internal RAID section. If the power
distribution board in the system has J12 populated, then incorrectly attaching the cable could cause
damage to the power distribution board or the RAID sensor card. When replacing the internal RAID
section assembly or power distribution board, remove the cable MCBL107A from the system. This
cable is not required for proper system operation.
