Intergraph StudioZ RAX - System Level Functional Diagram

60
System Level Functional Diagram
I/O Expansion
Board
(MSMT330)
Processor
Board
(MSMT329)
AC Filter
Circuit Breaker
Switch
Terminal
Block
Power
Distribution (AC
Box or UPS)
AC In
Monitor
Keyboard
Mouse
SCSI
Port
Parallel
Port
Serial
Ports
I/O Connector
Board
(MSMT328)
Intruder
Alert
Internal RAID Section
(MESAN200)
LCD Board (MPCBD20)
CDSK094 for StudioZ RAX only.
Optional drive or empty in InterServe.
System Keyswitch
Combo Drive (MESAM86)
System Fans
(MESAN160)
Power
Supply
Power
Supply
Power
Supply
Power Distribution Board
(MSMT331 or MSMT385)
CD-ROM Drive (CDSK132)
Fixed Disk Drive (CDSK094)
Part Page Part Page
Power distribution n/a Intruder Alert 90
Power distribution board (MSMT331
or MSMT385)
79 Keyboard n/a
I/O expansion board (MSMT330) 66 Monitor 89
I/O connector board (MSMT328) 76 System fans (MESAN16) n/a
Processor board (MSMT329) 61 Combo drive (MESAM86) 95
LCD Board (MPCBD20) 79 CD-ROM drive (CDSK132) 92
Internal RAID section (MESAN20) 84 Disk drive (CDSK094) 94
