5 System Hardware Information
This chapter contains technical information about the boards, and other hardware that comes standard
with the InterServe 650, 660 and StudioZ RAX systems. The following hardware items are described.
u
Processor board (MSMT329)
u
I/O expansion board (MSMT330)
u
I/O connector board (MSMT328)
u
LCD panel (MPCBD20)
u
Power Distribution board (MSMT331 or MSMT385)
u
Internal RAID Section (MESAN20)
u
Intruder Alert
u
Peripherals
u
System Fans
If your system includes any of the following hardware, refer to the documentation delivered with that
hardware for additional information:
u
RAID controller (CINF917)
u
InterRAID-8 cabinet (FDSK459/473/487/488)
u
100 Base-T Fast Ethernet card (CINF920)
u
InterSite Server Monitor (CINF029), InterServe only
u
Concentrator (FINF924 or FINF925), InterServe only
u
Uninterruptible Power Supply (MPWS144)
u
StudioZ card (MSMT297), StudioZ RAX only
u
RealiZm Z10T (MESAM96), StudioZ RAX only
u
Professional Audio sound card (CINF094), StudioZ RAX only
u
PC Extender (CINF033), StudioZ RAX only
