Monitors
15-inch, 17-inch, and 21-inch multiple sync monitors are supported. Refer to monitor documentation
for technical information about monitor hardware. Resolutions and refresh rates for Intergraph
monitors are:
u
Intergraph 15-inch (MDSP140) - up to 1024x768 and refresh rates up to 75 MHz.
u
Intergraph 17SD86 (MDSP141) - up to 1600x1200 and refresh rates up to 65 Hz. The maximum
supported horizontal refresh rate is 86 KHz.
u
Intergraph 21SD82 (MDSP131) - up to 1600x1200 and refresh rates up to 65 Hz. The maximum
supported horizontal refresh rate is 82 KHz.
u
Intergraph 21SD95 220 MHz (MDSP142) - up to 1600x1200 and refresh rates up to 75 Hz. The
maximum supported horizontal refresh rate is 95 KHz.
u
Intergraph 21SD107 220 MHz (MDSP139) - up to 1600x1200 and refresh rate of 80 Hz. The
maximum supported horizontal refresh rate is 107 KHz.
InterServe 650, 660 systems support remote monitors using the concentrator (FINF924 or FINF925).
The concentrator allows 7 feet, 25 feet, or 50 feet cable lengths. One 25-foot cable set is standard for
each concentrator.
StudioZ RAX supports remote monitors via the PC Extender (CINF033). The PC extender allows the
monitor (and mouse and keyboard) to be used over 100 feet from the system. One 100-foot UTP
category five cable set is standard for each workstation. The cables can be extended to 300 feet using
standard UTP category five cables.
NOTE The stereo mode of the RealiZm video display driver cannot be used when the monitor is connected to
the PC Extender. The monitor display appears pink and distorted.
