2 Installing the InterServe 650, 660
This chapter provides instructions for installing the InterServe equipment into the Intergraph rack. The
equipment is secured in the rack along the side mounting posts, which have industry standard
7.1 mm diameter mounting holes along the edge. The mounting posts have small round markers to
designate each vertical unit. There are three mounting holes per U, and at every 4 U there is a small
square marker. The total vertical mounting height within the rack is 40 U.
The system components should be installed in the following order:
u
Uninterriptible Power Supply (UPS)
u
InterRAID-8 disk array cabinet
u
InterServe base unit
u
Rackmount interface (keyboard, mouse, monitor)
u
RAID disk drives
u
System power and data cables
u
Rack cable handlers
u
Accessory components
WARNING Follow the installation instructions explicitly to avoid personal injury and damage to the server
hardware.
CAUTION To keep the rack from moving, ensure the front and side stabilizers are fully engaged and the leveling
feet are lowered firmly to the floor before installing equipment into the rack.
Note the following points before installing equipment into the rack:
u
The rack must be properly set up before placing any equipment into the rack. If installing the
equipment into an Intergraph rack, follow the instructions in Intergraph Rack Installation and Use
(DHA0194x) supplied with the rack.
u
Do not start the system until it has been completely set up. After setup is complete, refer to the
System Setup for startup and configuration instructions.
u
As equipment is installed into the rack, some components may not align properly with the holes in
the mounting posts. This occurs because some components have different tolerances in regards to
their height. If components do not align properly, loosen their screws and adjust support rails and
shelves where necessary so the components can be suppoerted by the proper shelves or rails, rather
than by the component underneath.
