For the pinout of MCBL087A connected to J16 and J17, refer to “Internal RAID Section
(MESAN20)”. See table “JP5, MCBL087A, Internal RAID Section Drives Power” on page 85. For
the pinout of MCBL095A connected to J10, see table “J4, MCBL095A, Internal RAID LCD” omn
page X.
J1, MCBL097A, LCD screen and controls
Pin
Signal Pin Signal Pin Signal
1 Ground 13 Data 6 24 VCC Fuse
2 +5V Fuse 14 Data 7 25 CHBAD
3 Ground 15 VCC Fuse 26 CHGOOD
4 DISPRS 16 Menu 27 PSBAD
5 DISPRW 17 Escape 28 PSGREEN
6 DISPENB 18 Down 29 FANBAD
7 Data 0 19 Enter 30 FANGREEN
8 Data 1 20 Up 31 Ground
9 Data 2 21 System/RAID 32 Bell
10 Data 3 22 No Connect 33 No Connect
11 Data 4 23 Ground 34 No Connect
12 Data 5
J2, MCBL086A, Combo Drive Power
Pin
Signal Wire Color
1 +12V Yellow
2 Ground Black
3 Ground Black
4 VCC Red
J3, MCBL099A, System Keyswitch
Pin
Signal Wire Color
1 System Reset Yellow
2 No Connect Black
3 Ground Black
4 System On Red
J8, MCBL085A, SCSI Drive Power
Pin
Signal Wire Color
1 +12V Yellow
2 Ground Black
3 Ground Black
4 VCC Red
