14
5. To retract the keyboard and mouse tray, press the rail tabs on both sides of the tray, then push the
tray into the rack.
Push in to retract
keyboard tray.
To install the monitor into the rack:
1. Remove the monitor cover plate from the rack. Screws are located at each corner and along the
bottom of the plate.
Screws
Monitor
Cover
Plate
Screw
