Intergraph StudioZ RAX - Memory Subsystem Description

52
4
3
2
1
5
6
B
A7
8
Find No.
Intergraph
Part No.
Description
Reference
Page
1 CFAB371F Front top cover n/a
2 MMSA4010 5.25-inch peripheral bracket n/a
3 CDSKxxx CD-ROM Drive 84
4 CDSK094 2 GB fixed disk drive (StudioZ RAX only) 85
4 CFAB558F Disk drive tray n/a
5 CFAB364F Airflow baffle n/a
6 MESAN160 Hot swappable system fan n/a
7 MMSA4070 3.5-inch drive bracket n/a
8 MESAM86 Combo drive 86
