Intermec EasyCoder PD41 Service Manual

Chapter 2 — Models and Options
12 EasyCoder PD41/PD42 Printer Service Manual
Models
The EasyCoder PD41/PD42 printer is available with a 200 or 300 dpi
printhead. The label taken sensor is installed into all printers. The Real
Time Clock module is in the PD42 only and is supported by the
Fingerprint firmware.
The PD42 is best described as an enhanced version of the PD41, which
comes equipped with a display, larger memory, real time clock, and a USB
host interface as a standard. The dimensions of the two printers are
identical.
All models ship with either Fingerprint or IPL firmware pre-installed.
EasyCoder PD41 printer
Note: All error messages in this version of the service manual relate to
Fingerprint. IPL specific error messages are not covered in this manual.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
