Intermec EasyCoder PD41 Service Manual

Chapter 3 — Replacing Parts
70 EasyCoder PD41/PD42 Printer Service Manual
Replacing the Main Board
To replace the main board
1 Disconnect the power cord and remove the left-hand panel (For help,
see “To remove the left-hand panel” on page 27).
2 Disconnect all cables from the main board (it may be a good idea to
label them first).
3 Remove any CompactFlash memory card.
4 Remove any Ethernet and parallel interface option boards.
5 Remove the five screws and washers that hold the main board.
6 Lift out the main board and install in reverse order.
The electronic compartment contains wires and components with
dangerous voltage. Always switch off the power and unplug the power
cord before you remove the cover over the electronics compartment!
Im Elektronikfach gibt es Kabel und Komponenten, die hohe
Spannungen führen. Immer die Stromversorgung abschalten und das
Netzkabel abziehen, bevor die Abdeckung des Elektronikfachs
abgenommen wird!
Do not attempt to replace individual components on the main board.
Replace the entire board instead.
Nicht versuchen, einzelne Komponenten auf der Hauptplatine
auszutauschen. Es muss die gesamte Platine ausgetauscht werden.
Take standard precautions against ESD (Electrostatic Discharges)
before touching any electronics components.

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
