Intermec EasyCoder PD41 Service Manual

Chapter 2 — Models and Options
14 EasyCoder PD41/PD42 Printer Service Manual
Technical Specifications
EasyCoder PD41 Printer
Physical Dimensions
Dimensions (WxLxH) 276 x 454.4 x 283.0 mm
(10.9 x 17.9 x 11.2 in)
Weight (excl. media) 13 kg (28.7 pounds)
Power Supply
Input rating ~100-240V 2-1A 50/60 Hz
Power consumption • Stand-by: 12 W
• Normal operation/printing: 80 W
• Peak: 250 in
Printing
Print technique Direct Thermal/Thermal Transfer
Printhead resolutions 8 dots/mm (203.2 dpi) or
11.8 dots/mm (300 dpi)
Print speed
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
50.8 to 152.4 mm/sec (2 to 6 in/sec)
50.8 to 101.6 mm/sec (2 to 4 in/sec)
Print Width Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
104 mm (4.1 in)
105.7 mm (4.2 in)
Print Length Max.
8 dots/mm (203 dpi)
11.8 dots/mm (300dpi)
Fingerprint
1270 mm (50 in)
558.2 mm (22 in)
IPL
600 mm (23 in)
406.4 mm (16 in)
Modes of Operation
Tear-off (straight-through) Yes
Cut-off Option with cutter
Peel-off (self-strip) Option with internal
rewinder
Firmware (Fingerprint)
Operating system Fingerprint v10.x.x Includes Direct Protocol
Smooth fonts TrueType and TrueDoc fonts
Resident scalable fonts 15
Character sets • 23 single-byte character sets standard.
• UTF-8 support as standard.
Resident bar codes 61

Intermec EasyCoder PD41 Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power requirements	100-240 VAC ±10%, 45-65 Hz
Media thickness	2.3 - 9.8 mm
Maximum label width	104 mm
Maximum label length	0.15 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	453 mm
Width	273 mm
Height	270 mm
Weight	13000 g
