Chapter 4 — Interfaces
84 EasyCoder PD41/PD42 Printer Service Manual
Communication Interfaces
The image below shows the location of the interface connectors on the rear
plate of the printer.
Interface Connectors
RS-232 Serial Interface
As a standard, the EasyCoder PD41/PD42 printer is equipped with an RS-
232 communication port. The circuitry is fitted on the CPU board and has
a fixed set of signals in a DB-9pin socket, which protrudes through a slot in
the printer’s rear plate.
I
O
Ethernet RJ-45 port
USB port
RS-232 serial port
IEEE 1284 parallel port
USB host port (PD42 only)
