Chapter 3 — Replacing Parts
24 EasyCoder PD41/PD42 Printer Service Manual
Console PCB: Schematics
COMPON ENT PLACEMENT REF.
TOP SIDE VIEW
P1
D4
SW1
D3
GREEN
BLUE
D2
GREEN
D1
RED
GREEN
220
D2
LED_3MM
5V
5V
5V
D1
4
6-PIN
P1
1
2
6
5
3
4
SW1
2
1
3
RED
R1
LED_3MM
220
R2
BLUE
5V
560
R3
LED_3MM
5V
LED_3MM
D4
220
R4
GREEN
D3
