SECTION 4—FRONT RIGGINGS
Spree XT 34 Part No 1118364
Installing/Removing Lift-Off Footrest
NOTE:Forthisprocedure,refertoFIGURE4.2.
Installing
1. Insertthefootrestassemblymountingpinsintothemountingtubeofthewheelchair
frame.
2. RepeatSTEP1fortheotherfootrestassembly.
3. Ifnecessary,adjustthefootrestheight.RefertoAdjustingFootrestHeightonpage 35.
Removing
1. Pushthefootrestreleaseleverinwardandliftfootrestupward.
2. RepeatSTEP1foroppositeside,ifnecessary.
FIGURE 4.2 Installing/Removing Swingaway Footrest
Footrest Release Lever
Footrest Assembly
Mounting Tube
Wheelchair Frame
Footplate
NOTE:Only60°Footrest
shownforclarity.Otherswill
attachthesameway.
Mounting Pin
