SECTION 5—ARMS
Part No 1118364 51 Spree XT
Adjusting T-Arm Transfer Assists And/or Side Guards
NOTE:Forthisprocedure,refertoFIGURE5.13.
1. RemovetheT‐Armfromthewheelchair.RefertoInstalling/RemovingT‐Armson
page 47.
2. Removethetwosocketscrewsthatsecurethesideguardtothebottomclamp.
NOTE:Adjustingthesideguardswilldirectlyaffectthepositionofthetransferassist.
3. Performoneofthefollowing:
•SmallSideGuards‐Movethebottomclampuptooneoftwomountingpositions
inthesideguard.
• LargeSideGuards‐Movethebottomclampuptooneofthreemountingpositions
inthesideguard.
4. Securethesideguardtothebottomclampwiththetwosocketscrews.
5. InstalltheT‐Armontothewheelchair.RefertoInstalling/RemovingT‐Armson
page 47.
FIGURE 5.13 Adjusting T-Arm Transfer Assists And/or Side Guards
Socket
Screws
Bottom Clamp
Transfer
Assist
Side Guard
T-Arm
