SECTION 5—ARMS
Spree XT 44 Part No 1118364
Adjusting Locking Cantilever Arm Angle
NOTE:Forthisprocedure,refertoFIGURE5.3.
NOTE:Thisadjustmentisrecommendedifthebackanglehasbeenchangedtokeeparmparallel
totheground/floor.
1. Flipthecantileverarmupandoutoftheway.
2. Removethelocknutthatsecuresthelockingpintothearmadjustmentplate.
3. Determinethemountingholeinthearmadjustmentplatethatwillbeusedto
correspondtothebackangle(FIGURE5.3).
4. Securelytightenthelockingpinandwashertotheadjustmentplatewithalocknut.
5. RepeatSTEPS1‐4fortheoppositeside,ifnecessary.
FIGURE 5.3 Adjusting Locking Cantilever Arm Angle
Locking Pin
Adjustment Plate
Locknut
Washer
DETAIL “A” - CORRESPONDING ARM ADJUSTMENT TO BACK ANGLE
Arm
Adjustment
Plate
Back Angle Bracket
86°
Arm
Adjustment
Plate
Back Angle Bracket
90°
Arm
Adjustment
Plate
Back Angle Bracket
94°
Arm Adjustment
Plate
Back Angle Bracket
98°
Arm
Adjustment
Plate
Back Angle Bracket
102°
Arm Adjustment
Plate
Back Angle Bracket
106°
NOTE:Thisadjustmentwillensurethearmisparalleltotheseat.
