SECTION 5—ARMS
Part No 1118364 45 Spree XT
Using/Installing/Adjusting Non-Locking Cantilever
Arms
 WARNING
DO NOT use lap trays with non-locking cantilever arms.
Using Non-Locking Cantilever Arms
 WARNING
DO NOT use lap trays with non-locking
cantilever arms.
NOTE:Forthisprocedure,referto
FIGURE5.4.
1. Pulltheendofthecantileverarmdown
tolowerthecantileverarm.
2. Pulltheendofthecantileverarmupto
moveitoutoftheway.
FIGURE 5.4 Using Non-Locking Cantilever
Arms
Installing Non-Locking Cantilever Arms
NOTE:Forthisprocedure,refertoFIGURE5.5.
1. Removethelocknutandwasherfrom
thelowerhexboltinstalledonthe
non‐lockingcantileverarm.
2. Slidehexboltofthecantileverarm
assemblyintothedesiredbackcane
mountinghole.
3. Securethecantileverarmtothe
wheelchairwithawasherandlocknut.
4. Adjust
theangleofthecantileverarm,
ifnecessary.RefertoAdjusting
Non‐LockingCantileverArmAngleon
page 46.
FIGURE 5.5 Installing Non-Locking
Cantilever Arms - Adjusting Non-Locking
Cantilever Arm Height
Back Cane
Cantilever Arm
Rear
Coved Washers and
Spacer
Locknut
Washer
Lower Hex Bolt
Cantilever Arm
Back Cane
