Invacare Spree XT - Adjusting T-Arm Sockets

SECTION 5—ARMS
Spree XT 50 Part No 1118364
Adjusting T-Arm Sockets
NOTE:Forthisprocedure,referto
FIGURE5.12.
NOTE:PerformthisprocedureiftheT‐Armis
toolooseinthesocketordoesnoteasilyslide
UPandDOWNinthesocket.
1. Removetherearwheelsfromthe
wheelchair,ifnecessary.Referto
Installing/RemovingRearWheelson
page 65.
2. Loosen,butDONOTremovethefour
hexscrewsandwashersthatsecure
T‐ArmsockettoT‐Armclamp.
NOTE:TheT‐Armsocketwilldisassembleif
thefourhexscrewsandwashersareremoved.
FIGURE 5.12 Adjusting T-Arm Sockets
3. SlidetheT‐ArmintotheT‐ArmsocketuntilthelockingleverisintheslotintheT‐Arm
socketandanaudibleʺclickʺisheard.
4. SqueezetheT‐ArmsocketandtheT‐Armclamptogetheruntilthesocketisflushwith
theT‐Arm.
5. WhileholdingtheT‐ArmsocketandtheT‐Armclamptogether,tightenthefourhex
screwsandwashers.Tightensecurely.
6. PressinonthelockingleverandlifttheT‐ArmstraightupandoutoftheT‐Arm
socket.
7. RepeatSTEPS3‐6,ifnecessaryuntiltheT‐ArmslidesintheT‐Armsocketasdesired.
8. Ifnecessary,installrearwheels.RefertoInstalling/RemovingRearWheelsonpage 65.
Hex Screws
and Washers
T-Arm
Hex Screws
and Washers
T-Arm Socket
T-Arm Clamp
Locking Lever
Slot
