SECTION 7—WHEELS/FORKS
Spree XT 60 Part No 1118364
Permanent Axle
NOTE:Forthisprocedure,refertoFIGURE7.2.
NOTE:Toremoverearwheels,reversethisprocedure.
1. Removethepermanentaxlesfromthepackagedcontainer.
2. Installpermanentaxlethroughtherear
wheelandaxlemountingplate.
3. Securelytightenthewheeltothe
wheelchairframewithlocknut.
NOTE:Only12‐inchrearwheelisshown.
All
otherwheelswillinstall/removeinthesame
manner.
4. RepeatSTEPS2‐3forotherrearwheel
assembly.
5. Adjustthewheellocks.Referto
AdjustingtheQuick‐ReleaseAxle
on
page 60.
FIGURE 7.2 Removing/Installing Rear
Wheels - Permanent Axle
Adjusting the Quick-Release Axle
NOTE:Forthisprocedure,refertoFIGURE7.3.
1. Removerearwheelandquick‐releaseaxlefromthewheelchair.Referto
Removing/InstallingRearWheelsonpage 59.
2. Depressdetentpininthequick‐releaseaxleandslideaxlethroughthewheelhub.
3. Increaseordecreaseendplayinthe
quick‐releaseaxlebyadjustingthe
locknutontheendofthequick‐release
axle.
4. Reinstallrearwheelontothe
wheelchair.Referto
Removing/InstallingRearWheelson
page 59.
5. Releasedetentpinensuringthatthe
lockingpinsarefullyreleased.
6. RepeatSTEPS3‐5untilthe
quick‐releaseaxlelocksproperly.
7. RepeatSTEPS1‐6foroppositeside,if
necessary.
FIGURE 7.3 Adjusting the Quick-Release
Axle
Permanent Axle
Rear
Wheel
Locknut
Axle Mounting
Plate
Wheelchair Frame
Rear Wheel
(Reference)
Locking Pin
Detent Pin
Quick-release
Axle
Axle Mounting
Plate
Locknut
Wheel Hub
(Reference)
