Installing/Replacing Chest Positioning Straps
NOTE:Forthisprocedure,refertoFIGURE6.7.
Installing
1. Positionthechestpositioningstraptooneoftheholesonthebackcane.
NOTE:Thestandardre commendedpositionforthechestpositioningstrapisinthetopholeofthe
backcane,butmaybemountedaccordingtotheuserʹsneeds.
2. Securethechestpositioningstraptothebackcaneswiththenew/existinghexscrew
andlocknut(FIGURE6.7).
3. RepeatSTEPS1‐2foroppositeside.
Replacing
1. Removethehexscrewthatsecuresthechestpositioningstraptothebackcane.
2. Discardexistingchestpositioningstrap.
3. RepeatSTEPS1‐2foroppositeside,ifnecessary.
4. Installthenewchestpositioningstrap.RefertoInstallingonpage 58.
FIGURE 6.7 Installing/Replacing Chest Positioning Straps
Back Cane
Locknut
Chest Positioning Strap
Hex Screw
