SECTION 11—TRANSPORT READY OPTION
Part No 1118364 73 Spree XT
Securing the Occupant
Wheelchair-Anchored Belts
 WARNING
The pelvic belt that is provided by Invacare has been tested for use in a motor
vehicle on this wheelchair ONLY. DO NOT replace the pelvic belt with a different
style pelvic belt.
NOTE:Forthisprocedure,refertoFIGURE11.1.
Thewheelchairhasbeenprovidedwithapelvicbeltwhichmeetstherequirementsof
ANSI/RESNAWC/19.
ThepelvicbeltprovidedbyInvacarehasbeendesignedtoaccommodateuseoneither
sideofthevehicle.Ifnecessary,followtheinstructionsbelowtoreversetheorientationof
thepelvicbelttoaccommodatethevehicle‐anchoreduppertorsobelt.
1. Installthepelvicbeltpin(DetailʺAʺofFIGURE11.1)intoslotinthepelvicbelt
bracket.Pullupwardsuntilitsnapsintoplace.
NOTE:Notethepositionofthemaleendofthebeltwheninstallingthepelvicbeltontothepelvic
beltbrackets.Themaleendofthepelvicbelt(DetailʺAʺofFIGURE11.1)hasapinwhichisused
tosecurethevehicle‐anchoreduppertorsobelt.
2. RepeatSTEP1fortheoppositepelvicbeltbracket.
3. Installthevehicle‐anchoreduppertorsobeltontothepinonthemaleendofthepelvic
belt.
FIGURE 11.1 Securing the Occupant
DETAIL “A” -
PELVIC BELT
Pelvic Belt
Slot
Tie-Down
Bracket
Pin (Used to secure
the vehicle anchored
upper torso belt.)
