SECTION 6—BACK/SEAT
Part No 1118364 57 Spree XT
Installing/Replacing Seat Positioning Straps
NOTE:Forthisprocedure,refertoFIGURE6.6.
Installing
1. Removethehexscrewandlocknutthatsecuresthebackcanetothebackplate.
2. Positiontheseatpositioningstrapagainstthebackplate.
3. Installthehexscrewthroughtheseatpositioningstrap,covedspacersandbackcane.
4. Securelytightentheseatpositioningstraptothewheelchairwiththelocknut.
5. RepeatSTEPS1‐4foroppositeside.
Replacing
1. Removethehexscrew,locknutandseatpositioningstrapfromthebackplateofthe
wheelchairframe.
2. Discardexistingseatpositioningstrap.
3. Installthenewseatpositioningstraptothewheelchair.RefertoInstallingonpage 57.
FIGURE 6.6 Installing/Replacing Seat Positioning Straps
Seat Positioning Strap
Hex Screw
Locknut
Back Plate
Back Cane
Coved Spacers
