Invacare Spree XT - Adjusting T-Arm Width; Adjusting T-Arm Depth

SECTION 5—ARMS
Part No 1118364 49 Spree XT
Adjusting T-Arm Width
NOTE:Forthisprocedure,refertoFIGURE5.10.
1. Removethetwomountingscrewsthat
securethearmpadtothearmtube.
2. Turnthearmpadaroundand
repositionthearmpadonthearmtube.
3. Re‐securethearmpadtothearmtube
withthetwomountingscrews.Tighten
securely.
4. Repeatfortheoppositeside,if
necessary.
FIGURE 5.10 Adjusting T-Arm Width
Adjusting T-Arm Depth
NOTE:Forthisprocedure,refertoFIGURE5.11.
1. Removethetwomountingscrewsthatsecurethearmpadtothearmtube.
2. RemovethetwosocketscrewsthatsecurethearmtubetotheT‐Armpost.
3. RepositionthearmtubeontheT‐Armpost:
•DeskLengthArms‐tooneofthree
positionsdependingonthedesired
armpaddepth.
•FullLengthArms‐tooneoffive
positionsdependingonthedesired
armpaddepth.
NOTE:Twoadditionalpositionsare
obtainablebyturningthearmtube180°.
4. Re‐securethearmtubetotheT‐Arm
postwiththetwosocketscrews.
Torque
to60‐70in.‐lbs.
5. Reattachthearmpadtothearmtube
withthetwomountingscrews.Tighten
securely.
FIGURE 5.11 Adjusting T-Arm Depth
6. Repeatfortheoppositeside,ifnecessary.
Mounting
Screw
Arm Tube
Mounting
Screw
Arm Pad
Socket
Screws
Arm Pad
Mounting
Screw
T-Arm
Post
Arm Tube
Mounting
Screw
