Invacare Spree XT - Installing Locking Cantilever Arms; Adjusting Locking Cantilever Arm Height

SECTION 5—ARMS
Part No 1118364 43 Spree XT
Installing Locking Cantilever Arms
NOTE:Forthisprocedure,refertoFIGURE5.2.
NOTE:Whenremovingthelocknutsandwashersfromthecantileverarmassembly,leavethetop
hexbolt,covedwashersandspacer(betweenadjustmentplateandcantileverarm)inplace.
1. Slidethepartiallyassembledcantileverarmassemblywithmountinghardware
throughthebackcane.Makesuretheadjustmentplateistowardstheinsideofthe
wheelchair.
NOTE:Thisincludestophexbolt,covedwashersandspacer(betweenadjustmentplateand
cantileverarm).
2. Slidethebottomhexbolt(w/covedwasher)throughtheadjustmentplateandback
cane.
3. Securelytightenthecantileverarmtothewheelchairwithtwolocknutsandwashers.
4. Adjusttheangleofthecantileverarm,ifnecessary.RefertoAdjustingLocking
CantileverArmAngleonpage 44.
Adjusting Locking Cantilever Arm Height
NOTE:Forthisprocedure,refertoFIGURE5.2.
NOTE:Whenremovingthelocknutsandwashersfromthecantileverarmassembly,leavethetop
hexbolt,covedwashersandspacer(betweenadjustmentplateandcantileverarm)inplace.
1. Removethetwolocknutsandwasherssecuringthecantileverarmassemblytothe
backcane.
2. Removethecantileverarmassemblywithhardwarefromthebackcane.
3. PerformSTEPS1‐4inInstallingLockingCantileverArmsonpage 43torepositionthe
armatthedesiredheight.
FIGURE 5.2 Installing Locking Cantilever Arms - Adjusting Locking Cantilever Arm Height
Locknuts
Washers
Back Cane
Adjustment Plate
Coved
Washers
Actuator
Spacer
Top Hex Bolt and
Coved Washer
Bottom Hex Bolt
Cantilever Arm
