SECTION 4—FRONT RIGGINGS
Part No 1118364 35 Spree XT
Adjusting Footrest Height
Height Adjustment Ranges
NOTE:Ifusinganytypeofextensionwiththeadjustableflip‐upfootplate.RefertoAdjusting
AdjustableAngleFlip‐UpFootplatesonpage 37.
60°, 70° and 70° Taper
NOTE:Forthisprocedure,refertoFIGURE4.3.
1. Removethefootrestfromthe
wheelchair.Referto
Installing/RemovingSwingaway
Footrestonpage 33.
2. Removethehexscrewandcoved
spacerandslidethefootrestupor
downonitsmountingtubeuntilthe
desiredfootrestheightisachieved.
3. Reassemblethehexscrewandcoved
spacerthroughthefootrestupper
supportandmountingtube(FIGURE
4.3).
FIGURE 4.3 Adjusting Footrest Height -
60°, 70° and 70° Taper
4. Securelytightenthehexscrewand
covedspacer.
5. Installthefootrestassemblyontothewheelchair.RefertoInstalling/Removing
SwingawayFootrestonpage 33.
6. RepeatSTEPS1‐5fortheoppositesideofthewheelchair,ifnecessary.
70° MFX, 90°, 70° LIFT and 90° LIFT Footrests
NOTE:Forthisprocedure,refertoFIGURE4.4.
1. Removeanyaccessoriesthatareattachedtothefootrests.
2. Removethesocketbolt,covedwasherandlocknutthatsecurethefootplatetothe
footrestsupport.
3. Repositionthefootplatetothedesiredheight.
FOOTREST TYPE ADJUSTMENT RANGE
60° 13-17-inches
70° 13-17-inches
90° 5-8-inches
90° 5-11-inches (with 3-inch extension)
Footrest
Mounting
Tube
Coved
Spacer
Hex Screw
Footrest Upper
Support
