SECTION 4—FRONT RIGGINGS
Part No 1118364 41 Spree XT
Installing Impact Guards/Calf Strap/H-Calf Strap
NOTE:Forthisprocedure,refertoFIGURE4.12.
NOTE:Impactguardsarestandardequipment
onModelSTfootrests.Noassemblyisrequired.
1. Removeimpactguard/calfstrapfrom
packagedcontainer.
2. Securetheimpactguardstothefootrest
frame.
3. Securethecalfstraparoundthefootrest
frame(withtheimpactguards
attached).
FIGURE 4.12 Installing Impact Guards/Calf
Strap/H-Calf Strap
H-Calf
Strap
Calf
Strap
Impact Guard
