SECTION 5—ARMS
Spree XT 42 Part No 1118364
SECTION 5—ARMS
 WARNING
NEVER try to lift or tip the wheelchair by the arms, serious injury can occur.
After any adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.
Using/Installing/Adjusting Locking Cantilever Arms
Using Locking Cantilever Arms
NOTE:Forthisprocedure,refertoFIGURE5.1.
1. Pushthelockingmechanismactuatortowardsthefrontofthewheelchair.
2. Whileholdingthelockingmechanismactuator,pulluponthecantileverarmtowards
therearofthewheelchair.
NOTE:Ifnecessary,thelockingmechanisminthecantileverarmcanberepositionedsothe
cantileverarmwillopendowninsteadofup.Forthisadjustment,contactaqualifiedtechnician.
3. Tolockthecantileverarm,pushdownuntilthereisanaudibleclick.
4. Pulluponthecantileverarmtomakesureitislockedinplace.
FIGURE 5.1 Using Locking Cantilever Arms
Front of Wheelchair
Locking Mechanism
Actuator
Cantilever Arm
Push
Rear of
Wheelchair
