Arm Pad Replacement for Cantilever Arms
NOTE:Forthisprocedure,refertoFIGURE5.7.
1. Removethemountingscrewsfromthearmrestpad.
2. ReplacewithNEWarmrestpad.
3. Securewithexistinghardware.
FIGURE 5.7 Arm Pad Replacement for Cantilever Arms
Installing/Removing T-Arms
NOTE:Forthisprocedure,refertoFIGURE5.8.
Installing T-Arms
1. PositiontheT‐ArmovertheT‐Arm
socketonthewheelchairframe.
NOTE:Makesurethelockingleveristowards
thefrontofthewheelchair.
2. SlideT‐ArmintoT‐Armsocketuntilthe
lockingleverisintheslotintheT‐Arm
socketandanaudibleʺclickʺisheard.
3. PullUPonT‐ArmtomakesureT‐Arm
islockedinplace.
NOTE:IftheT‐Armdoesnotslideinthe
T‐Armsocketasdesired,adjusttheT‐Arm
socket.RefertoAdjustingT‐ArmSockets
on
page 50.
4. AdjusttheT‐Armfordesiredheight,
widthanddepth,ifnecessary.Referto
AdjustingTheT‐Arms
onpage 48.
5. RepeatSTEPS1‐4foroppositesideof
wheelchair.
FIGURE 5.8 Installing/Removing T-Arms
Full Length Arm Pads
Desk Length
Arm Pads
Armrest Pad
Cantilever
Arm Tube
Mounting
Screws
Cantilever
Arm Tube
Mounting Screws
Arm Pad
Cantilever
Slide Tube
T-Arm
Socket
Locking Lever
(towards the front
of the wheelchair)
T-Arm
Wheelchair
Frame
Slot
