SECTION 6—BACK/SEAT
Part No 1118364 55 Spree XT
Installing/Removing/Adjusting the Adjustable Angle
Stroller Handles
NOTE:Forthisprocedure,refertoFIGURE6.4.
Installing
1. Removeplugbuttonsfrombothbackcanes.
2. Slidetheadjustableheightstrollerhandleintothebackcanes.
3. Alignthemountingholesoftheadjustableanglestrollerhandleandthebackcane.
4. Secureadjustableanglestrollerhandletothebackcaneswiththetwoquick‐release
pins(DetailʺAʺofFIGURE6.4).
5. Ifnecessary,adjusttheheight.RefertoAdjustingonpage 56.
Removing
1. Pressandholdthebuttonsonthequick‐releasepins
2. Removetheadjustableanglestrollerhandlefromthebackcane.
3. Installplugbuttons.
FIGURE 6.4 Installing/Removing/Adjusting the Adjustable Angle Stroller Handles
Back Canes
Stroller Handle
Detent
Ball
Quick-Release
Pins
Back Cane
Quick-Release Pin
DETAIL “A” -
QUICK-RELEASE
PIN INSTALLED
NOTE:Plugbuttons
notshownforclarity.
