SECTION 7—WHEELS/FORKS
Part No 1118364 61 Spree XT
Seat-to-Floor Height Adjustment
 WARNING
Repositioning the axle plates (seat-to-floor height) MUST be performed by a quali-
fied technician.
Adjusting Forks
NOTE:Forthisprocedure,refertoFIGURE7.4.
1. Removethedustcoverfromthecasterheadtube.
2. Toproperlytightencasterjournalsystemandguardagainstflutter,performthe
followingcheck:
A. Tipbackthewheelchairtofloor.
B. Pivotbothforksandcasterstotopoftheirarcsimultaneously.
C. Letcastersdroptobottomofarc(wheelsshouldswingoncetoone‐side,then
immediatelyrestinastraightdownwardposition).
D. Adjustlocknutsaccordingtofreedomofcasterswing.
3. Testwheelchairformaneuverability.
4. Readjustlocknutsifnecessary,andrepeatSTEPS1‐3untilcorrect.
5. Snapdustcov erintothecasterheadtube.
6. RepeatSTEPS1‐5foroppositeside,ifnecessary.
FIGURE 7.4 Adjusting Forks
Locknut
Top View
Dust Cover
Caster
Headtube
