Invacare Spree XT - Adjusting Adjustable Angle Flip-Up Footplates; Depth Adjustment; Angle Adjustment

SECTION 4—FRONT RIGGINGS
Part No 1118364 37 Spree XT
Adjusting Adjustable Angle Flip-Up Footplates
 WARNING
When determining the angle of the footplates, make sure the rear of the footplates
DO NOT interfere with the movement of the front casters. Otherwise, injury or
damage may occur.
NOTE:Forthisprocedure,refertoFIGURE4.6.
Depth Adjustment
1. Removethetwoflatscrewsandlocknutsthatsecurefootplatetothehalfclamp.
NOTE:Observetheangleofthefootplateforreinstallation.
2. Movethefootplatetooneoffourmountingpositions.
NOTE:Ifdesireddepthisstillnotobtained,rotatethehalfclamponthefootplatehinge180°.
3. Retightenthetwoflatscrewsandlocknuts.
NOTE:Thesettingforpositioningthefootplateonthehalfclampmayvaryforeachfootplate.
4. RepeatSTEPS1‐3foroppositefootplate,ifdesired.
Angle Adjustment
1. Loosen,butDONOTremovetheadjustmentscrewinthehalfclamp.
2. Positionthefootplatetothenecessaryangletoaccommodatetheuser(Detail“A”).
3. Retightentheadjustmentscrew.Torquetoover90in‐lbs,butnomorethan300in‐lbs.
4. RepeatSTEPS1‐3foroppositefootplate,ifdesired.
5. Screwinoroutuntiltheadjustableangleflip‐upfootplateisperpendiculartothe
footrestassemblyorthedesiredinversion/eversionisobtained.
FIGURE 4.6 Adjusting Adjustable Angle Flip-Up Footplates
Footplate
Hinge
90° Footrest Support
Flat Screws
Footplate
Half Clamp
Adjustment Screw
Locknuts
Footplate
Footrest Support
Detail “A” - Side View of Footplate and Footrest
Support
