INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-89-
Function
code
Name
Description
Default
P02.06
Stator resistance of
AM 1
0.001–65.535Ω
Depends
on model
P02.07
Rotor resistance of
AM 1
0.001–65.535Ω
Depends
on model
P02.08
Leakage inductance of
AM 1
0.1–6553.5mH
Depends
on model
P02.09
Mutual inductance of
AM 1
0.1–6553.5mH
Depends
on model
P02.10
No-load current of AM 1
0.1–6553.5A
Depends
on model
P02.15
Rated power of SM 1
0.1–3000.0kW
Depends
on model
P02.16
Rated frequency of
SM 1
0.01Hz–P00.03(Max. output frequency)
50.00Hz
P02.17
Number of pole pairs of
SM 1
1–50
2
P02.18
Rated voltage of SM 1
0–1200V
Depends
on model
P02.19
Rated current of SM 1
0.8–6000.0A
Depends
on model
P02.20
Stator resistance of
SM 1
0.001–65.535Ω
Depends
on model
P02.21
Direct-axis inductance
of SM 1
0.01–655.35mH
Depends
on model
P02.22
Quadrature-axis
inductance of SM 1
0.01–655.35mH
Depends
on model
P02.23
Counter-emf constant
of SM 1
0–10000
300
P05.01–
P05.06
Function selection of
multifunction digital
input terminals (S1–S4,
and HDIA)
35: Switch from motor 1 to motor 2
P08.31
Switching between
motor 1 and motor 2
0x00–0x14
Ones place: Switchover channel
0: Terminal
1: Modbus communication
2: PROFIBUS/CANopen communication
00
