INVT IPE300 Series User Manual

IPE300 series engineering VFD Basic operation guidelines
-92-
Setting
Function
Description
28
Superposing pulses
When the pulse superposition terminal input function is valid, the
output is valid.
29
STO action
When an STO fault occurs, the output is valid.
30
Positioning completed
When positioning is completed, the output is valid.
31
Spindle zeroing
completed
When spindle zeroing is completed, the output is valid.
32
Spindle scale division
completed
When spindle scale division is completed, the output is valid.
33
In speed limit
When the frequency is limited, the output is valid.
34
EtherCAT/PROFINET
communication virtual
terminal output
Output corresponding signal based on the set value of Ethernet;
output ON signal when it is set to 1, output OFF signal when it is
set to 0.
35
Reserved
36
Speed/position control
switchover completed
When the mode switchover is completed, the output is valid.
37–40
Reserved
41
C_Y1
C_Y1 from PLC (Set P27.00 to 1.)
42
C_Y2
C_Y2 from PLC (Set P27.00 to 1.)
43
C_HDO
C_HDO from PLC (Set P27.00 to 1.)
44
C_RO1
C_RO1 from PLC (Set P27.00 to 1.)
45
C_RO2
C_RO2 from PLC (Set P27.00 to 1.)
46
C_RO3
C_RO3 from PLC (Set P27.00 to 1.)
47
C_RO4
C_RO4 from PLC (Set P27.00 to 1.)
48–63
Reserved
Related parameter list:
Function
code
Name
Description
Default
P06.00
HDO output type
0: Open collector high-speed pulse output
1: Open collector output
0
P06.01
Y1 output
0: Disable
1: Running
2: Running forward
3: Running reversely
4: Jogging
5: VFD in fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
0
P06.02
HDO output
0
P06.03
RO1 output
1
P06.04
RO2 output
5
