INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-141-
Function
code
Name
Description
Default
Modify
P05.09
Digital input filter
time
The function code is used to set the filter time for
S1–S4, HDIA, and HDIB. In strong interference
cases, increase the value to avoid maloperation.
0.000–1.000s
0.010s
○
P05.10
Virtual terminal
setting
0x000–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: HDIB virtual terminal
0x00
◎
P05.11
Terminal control
mode
Used to set the mode of terminal control.
0: Two-wire control 1, the enabling consistent
with the direction. This mode is widely used. The
defined FWD/REV terminal command
determines the motor rotation direction.
FWD
REV
COM
K1
K2
Running
command
FWD REV
OFF OFF
OFF
OFF
ON
ON
ON ON
Stop
Hold
Forward
running
Reverse
running
1: Two-wire control 2, the enabling separated
from the direction. In this mode, FWD is the
enabling terminal. The direction depends on the
defined REV state.
FWD
REV
COM
K1
K2
Running
command
FWD REV
OFF OFF
OFF
OFF
ON
ON
ON ON
Stop
Stop
Forward
running
Reverse
running
2: Three-wire control 1. This mode defines Sin as
the enabling terminal, and the running command
is generated by FWD, while the direction is
controlled by REV. During running, the Sin
0
◎
