IPE300 series engineering VFD Function parameter list
-204-
Function
code
Name
Description
Default
Modify
0: No filter
1: Filter
Bit3: Enable/disable pulse reference
frequency-division output filter
0: No filter
1: Filter
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode (valid when
Bit4 is set to 1)
0: Self-adaptive filter
1: Use P20.19 filter parameter
Bit6: Frequency-divided output source setting
0: Encoder signals
1: Pulse reference signals
Bit7–15: Reserved
P20.18
Encoder pulse
filter width
0–63
The filter time is P20.18*0.25us. The value 0 or
1 indicates 0.25us.
10
○
P20.19
Pulse reference
filter width
0–63
The filter time is P20.19*0.25us. The value 0 or
1 indicates 0.25us.
10
○
P20.20
Pulse number of
pulse reference
0–65535
1024
◎
P20.21
Enabling SM
angle
compensation
0–1
0
○
P20.22
Frequency point
of speed
measurement
mode switchover
0–630.00Hz
Note: Valid only when P20.12=0.
1.00Hz
○
P20.23
SM angle
compensation
coefficient
-200.0–200.0%
100.0%
○
P20.24
Reserved
0–65535
0
○
