INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-223-
Function
code
Name
Description
Default
Modify
P25.24 setting range: 0.00V–P25.26
P25.25 setting range: -100.0% –100.0%
P25.26 setting range: P25.24–10.00V
P25.27 setting range: -100.0% –100.0%
P25.28 setting range: 0.000s–10.000s
P25.29 setting range: 0.00V–P25.31
P25.30 setting range: -100.0% –100.0%
P25.31 setting range: P25.29–10.00V
P25.32 setting range: -100.0% –100.0%
P25.33 setting range: 0.000s–10.000s
P25.34
HDI3 high-speed
pulse input
function
selection
0: Input set through frequency
1: Counting function
0
◎
P25.35
HDI3 lower limit
frequency
0.000 kHz – P25.37
0.000
kHz
○
P25.36
Corresponding
setting of HDI3
lower limit
frequency
-100.0%–100.0%
0.0%
○
P25.37
HDI3 upper limit
frequency
P25.35–50.000kHz
50.000
kHz
○
P25.38
Corresponding
setting of HDI3
upper limit
frequency
-100.0%–100.0%
100.0%
○
P25.39
HDI3 frequency
input filter time
0.000s–10.000s
0.030s
○
P25.40
AI3 input signal
type
Setting range: 0–1
0: Voltage
1: Current
0
○
P25.41
AI4 input signal
type
Setting range: 0–1
0: Voltage
1: Current
0
○
P25.42–P
25.45
Reserved
0–65535
0
○
