INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-230-
Function
code
Name
Description
Default
Modify
Tens place: Reference direction of CW1
0: Invalid (Forward by default)
1: Reference direction valid
Hundreds place: Reserved
Thousands place: DP drop control selection
0: Disable, common platform method adopted
1: Enable
P90.18
Bit 0 of CW 2
0: Disable
1: Drop control enabled
2: Heartbeat reference (0: no heartbeat; 1: The
RUN command in control word 1 and received
PZD are valid only when the heartbeat is enabled
and the bit is 1.)
3: Remote brake output (0: disable; 1: Brake
output relay is valid, corresponding to output
terminal 50: remote brake)
4: Clear encoder pulse count (0: disable; 1: Set
the present encoder pulse count value to the
value of P22.24)
5–16: Reserved
0
◎
P90.19
Bit 1 of CW 2
0
◎
P90.20
Bit 2 of CW 2
0
◎
P90.21
Bit 3 of CW 2
0
◎
P90.22
Bit 4 of CW 2
0
◎
P90.23
Bit 5 of CW 2
0
◎
P90.24
Bit 6 of CW 2
0
◎
P90.25
Bit 7 of CW 2
0
◎
P90.26
Bit 8 of CW 2
0
◎
P90.27
Bit 9 of CW 2
0
◎
P90.28
Bit 10 of CW 2
0
◎
P90.29
Bit 11 of CW 2
0
◎
P90.30
Bit 12 of CW 2
0
◎
P90.31
Bit 13 of CW 2
0
◎
P90.32
Bit 14 of CW 2
0
◎
P90.33
Bit 15 of CW 2
0
◎
P90.34
Bit 00 selection
of SW 1
0–47
0: Disable
1: Ready status after power on (0: invalid; 1:
valid)
OFF2/OFF3 invalid and OFF1 activated
2: Ready to run status (0: invalid; 1: valid)
OFF2/OFF3/OFF1 invalid
3: Running status (0: invalid; 1: running)
OFF2/OFF3/OFF1 invalid and RUN activited
4: Faulty status (0: Invalid; 1: Faulty)
5: OFF2 status (0: OFF2 activated; 1: disable)
6: OFF3 status (0: OFF3 activated; 1: disable)
7: Prohibit running status (0: invalid; 1: prohibit
running status)
OFF2/OFF3 activated
1
◎
P90.35
Bit 01 selection
of SW 1
2
◎
P90.36
Bit 02 selection
of SW 1
3
◎
P90.37
Bit 03 selection
of SW 1
4
◎
P90.38
Bit 04 selection
of SW 1
5
◎
P90.39
Bit 05 selection
of SW 1
6
◎
P90.40
Bit 06 selection
of SW 1
7
◎
