IPE300 series engineering VFD Function parameter list
-231-
Function
code
Name
Description
Default
Modify
P90.41
Bit 07 selection
of SW 1
8: Reserved
9: Speed deviation fault (0: speed deviation; 1:
invalid)
10: Remote control (0: disable; 1: remote)
11: Terminal or comunication remote (0: terminal;
1: communication)
12: Zero speed status (0: invalid; 1: zero speed)
13: Jogging status (0: invalid; 1: jogging)
14: Motor running direction (0: forward; 1:
reverse)
15: ACC/DEC (0: constant speed; 1: ACC/DEC)
16: Torque limit reached (1: the torque output
reaches the limit value)
17: Max. frequency reached (1: The frequency
reaches the maximum value.)
18: Motor running group (0: motor 1; 1: motor 2)
19: Motor type (0: AM; 1: SM)
20: End of excitation establishment (Related to
P03.25 in Vector 0 mode.) 0: invalid; 1:
excitation establishment ends)
21: Excitation status (0: invalid; 1: exciting)
22: Bus voltage established (0: not established;
1: established)
23: Heartbeat feedback (0: invalid; 1: heartbeat
feedback)
24: Master mode (0: disable; 1: master mode)
25: Slave mode (0: disable; 1: slave mode)
26: Overcurrent (0: invalid; 1: overcurrent)
27: Bus overvoltage (0: invalid; 1: overvoltage)
28: Bus undervoltage (0: invalid; 1: undervoltage)
29: Motor overload (0: invalid; 1: motor overload)
30: VFD overload (0: invalid; 1: VFD overload)
31: Torque control mode (0: disable; 1: torque
mode)
32–47: Reserved
8
◎
P90.42
Bit 08 selection
of SW 1
9
◎
P90.43
Bit 09 selection
of SW 1
10
◎
P90.44
Bit 10 selection
of SW 1
11
◎
P90.45
Bit 11 selection
of SW 1
0
◎
P90.46
Bit 12 selection
of SW 1
0
◎
P90.47
Bit 13 selection
of SW 1
0
◎
P90.48
Bit 14 selection
of SW 1
0
◎
P90.49
Bit 15 selection
of SW 1
0
◎
P90.50
Bit 0 of SW 2
0–63
0–31: Consistent with SW 1
32: Input phrase-loss (0: invalid; 1: input
phrase-loss)
33: Output phrase-loss (0: invalid; 1: output
0
◎
P90.51
Bit 1 of SW 2
0
◎
P90.52
Bit 2 of SW 2
0
◎
P90.53
Bit 3 of SW 2
0
◎
P90.54
Bit 4 of SW 2
0
◎
