IPE300 series engineering VFD Function parameter list
-232-
Function
code
Name
Description
Default
Modify
P90.55
Bit 5 of SW 2
phrase-loss)
34: VFD overheating (0: invalid; 1: VFD
overheating)
35: PT100 overtemp pre-alarm (0: invalid; 1:
overtemp pre-alarm)
36: PT100 overtemp (0: invalid; 1:
overtemperature)
37: PT1000 overtemp pre-alarm (0: invalid; 1:
overtemp pre-alarm)
38: PT1000 overtemp (0: invalid; 1:
overtemperature)
39: Motor overheating input (0: invalid; 1: motor
overheating)
40: VFD PoFF status (1: PoFF status)
41: Power-up buffer disconnect (0: invalid; 1:
disconnected)
42: S1 status
43: S2 status
44: S3 status
45: S4 status
46–47: Reserved
48: Brake status (0: braking; 1: brake released)
49: Release of braking control reference value (0:
invalid; 1: valid)
50: Release of braking control inverter (0: invalid;
1: valid)
51: Brake releasing error warning (0: invalid; 1:
valid)
52: Braking error warning (0: invalid; 1: valid)
53: Brake releasing torque verification passed (0:
invalid; 1: valid)
54: Brake releasing frequency verification passed
(0: invalid; 1: valid)
55–63: Reserved
0
◎
P90.56
Bit 6 of SW 2
0
◎
P90.57
Bit 7 of SW 2
0
◎
P90.58
Bit 8 of SW 2
0
◎
P90.59
Bit 9 of SW 2
0
◎
P90.60
Bit 10 of SW 2
0
◎
P90.61
Bit 11 of SW 2
0
◎
P90.62
Bit 12 of SW 2
0
◎
P90.63
Bit 13 of SW 2
0
◎
P90.64
Bit 14 of SW 2
0
◎
P90.65
Bit 15 of SW 2
0
◎
P90.66
Reverse
received CW 1
per bit
0x0000–0xFFFF
0x0000
◎
P90.67
Reverse
received CW 2
per bit
0x0000–0xFFFF
0x0000
◎
