INVT IPE300 Series User Manual

IPE300 series engineering VFD Function parameter list
-233-
Function
code
Name
Description
Default
Modify
P90.68
Reverse sent SW
1 per bit
0x0000–0xFFFF
0x0000
◎
P90.69
Reverse sent SW
2 per bit
0x0000–0xFFFF
0x0000
◎
P90.70
DP
communication
data interacts
with PLC card
0x0000–0x1111
Ones place: CW 1
0: disable
1: enable
Tens place: SW 1
0: disable
1: enable
Hundreds place: Received PZD2–PZD12
0: disable
1: enable
Thousands place: Sent PZD2–PZD12
0: disable
1: enable
0x0000
○
P90.71
DP special
function 1
selection
0x000–0x111
Ones place:
0: Disable
1: In Poff (main contact disconnected), faults can
be reset.
Tens place:
0: DP control word edge trigger active
1: DP control word level trigger active
Hundreds place:
0: Fault E-DP is reported at DP timeout
1: Fault A-DP is reported at DP timeout
0x0000
○
P90.72
OFF source
selection
0x000–0x444
Ones place: OFF1 command source
Tens place: OFF2 command source
Hundreds place: OFF3 command source
0: DP communication
1: S1
2: S2
3: S3
4: S4
Note: Tens place is valid when the tens place of
P90.16 is 1. Hundreds place is valid when the
hundreds place of P90.16 is 1.
0x000
○
