INVT IPE300 Series User Manual

IPE300 series engineering VFD Extension card
-298-
Name
Model
Specifications
diagram, and sequential function chart;
 Supporting resumable commissioning and task period
execution mode selection;
 Providing a user program storage space of 16K steps and
data storage space of 8K words;
 6 digital inputs:
 2 relay outputs;
 1 analog input and 1 output;
 1 RS485 communication channel, master/slave switchover
by upper computer;
 Supporting saving data of 1K words at power failure.
PROFIBUS-DP
communication
card
EC-TX503
Supporting the PROFIBUS-DP protocol
Ethernet
communication
card
EC-TX504
 Supporting Ethernet communication with INVT's internal
protocol
 Can be used in combination with INVT's upper computer
monitoring software INVT Workshop
CANopen
communication
card
EC-TX505
 Based on the CAN2.0A physical layer;
 Supporting the CANopen protocol.
CAN
master/slave
control
communication
card
EC-TX511
 Based on the CAN2.0B physical layer;
 Adopting INVT's master-slave control proprietary protocol.
PROFINET
communication
card
EC-TX509
Supporting the PROFINET protocol
Sin/Cos PG card
EC-PG502
 Applicable to Sin/Cos encoders with or without CD signals;
 Supporting A, B, Z frequency-divided output;
 Supporting pulse string setting.
Incremental PG
card with UVW
EC-PG503-05
 Applicable to differential encoders of 5 V
 Supporting the orthogonal input of A, B, and Z
 Supporting pulse input of phase U, V, and W;
 Supporting the frequency-divided output of A, B, and Z
 Supporting pulse string setting.
