INVT IPE300 Series User Manual

IPE300 series engineering VFD Extension card
-310-
Category
Terminal
symbol
Terminal name
Description
Digital
input/output
PS1—COM
Digital input 1
1. Internal impedance: 4kΩ
2. 12–30V voltage input is acceptable
3. Bi-direction input terminal
4. Max. input frequency: 1kHz
5. Source/sink input, and the input type should be
consistent.
PS2—COM
Digital input 2
PS3—COM
Digital input 3
PS4—COM
Digital input 4
PS5—COM
Digital input 5
PS6—COM
Digital input 6
PY1—CME
Digital output 1
1. Switch capacity: 200mA/30V
2. Output frequency range: 0–1kHz
3. The terminals CME and COM are shorted
through J1 before delivery.
PY2—CME
Digital output 2
Analog
input/output
AI1
Analog input 1
1. Input range: For AI1, 0–10V or 0–20mA
2. Input impedance: 20KΩ for voltage input or
250Ω for current input
3. Whether voltage or current is used for input is
set through the jumper
4. Resolution: 5mV when 10V corresponds to
50Hz
5. Deviation: ±1%, 25°C, full measuring range
AO1
Analog output 1
1. Output range: 0–10V or 0–20mA
2. Whether voltage or current is used for output is
set through the jumper
3. Deviation: ±1%, 25°C, full measuring range
Relay
output
PRO1A
NO contact of relay
1
Contact capacity: 2A/AC250V, 1A/DC30V
Cannot be used as high frequency digital output
PRO1C
Common contact of
relay 1
PRO2A
NO contact of relay
2
PRO2C
Common contact of
relay 2
For details about how to use the programmable card, see the Goodrive350 series AutoStation
programmable card manual.
