IPE300 series engineering VFD Basic operation guidelines
-52-
acceleration/deceleration time of voltage and frequency respectively, which form a real-time V/F curve
in combination manner.
Note: This type of V/F curve separation can be applied in various variable-frequency power sources.
However, exercise caution when setting parameters as improper settings may cause equipment
damage.
Function
code
Name
Description
Default
P00.00
Speed control mode
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
3: Closed-loop vector control mode
Note: If 0, 1 or 3 is selected, it is required to carry
out motor parameter autotuning first.
2
P00.03
Max. output
frequency
P00.04–400.00Hz
50.00Hz
P00.04
Upper limit of running
frequency
P00.05–P00.03
50.00Hz
P00.05
Lower limit of running
frequency
0.00Hz–P00.04
0.00Hz
P00.11
ACC time 1
0.0–3600.0s
Model
depended
P00.12
DEC time 1
0.0–3600.0s
Model
depended
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
P02.02
Rated frequency of
AM 1
0.01Hz–P00.03(Max. output frequency)
50.00Hz
P02.04
Rated voltage of AM 1
0–1200V
Model
depended
P04.00
V/F curve setting of
motor 1
0: Straight-line V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve (power of 1.3)
3: Torque-down V/F curve (power of 1.7)
4: Torque-down V/F curve (power of 2.0)
5: Customized V/F curve (V/F separation)
0
P04.01
Torque boost of motor
0.0%: (automatic)
0.0%
