10.6 Diagnostics tool
If the network connection fails, you can use the diagnostics tool included in the AP to locate
the faulty node.
10.6.1 Locating the faulty node
The link www.google.com is used as an example.
1. Click Tools > Diagnostics Tool.
2. Enter the IP address or domain name to be pinged in the Input box, which is
www.google.com in this example.
3. Click ping.
---End
The diagnosis result will be displayed in a few seconds in the black text box.
